Product Name: Support and Nozzle Tube Assembly

Description:
This component is a support and nozzle tube assembly for the cutting head of an abrasive waterjet system. The assembly consists of two main parts: a structural support (bracket or holder) and a nozzle tube (also known as a mixing tube or focusing tube). The support is typically a rigid stainless steel bracket that mounts the nozzle tube securely to the cutting head body. The nozzle tube is a precision-machined cylindrical component, usually made from tungsten carbide, through which the abrasive waterjet is focused and directed at the workpiece.

Applications:

• Securely mounts the mixing tube to the cutting head assembly

• Provides the final exit path for the abrasive waterjet

• Ensures precise alignment of the waterjet with the workpiece

• Suitable for both 3-axis and 5-axis abrasive waterjet cutting systems

Features:

• Rigid Support: The bracket provides stable, vibration-free mounting for the nozzle tube

• Tungsten Carbide Nozzle Tube: Highly wear-resistant material withstands abrasive erosion for extended service life

• Precision Alignment: Machined to exact tolerances for perfect coaxial alignment with the water orifice

• Threaded Connection: Secure attachment to the cutting head body via standard threads

Maintenance:

• Nozzle Tube Wear: Regularly inspect the nozzle tube exit orifice for ovality or flaring. Replace when cut quality degrades or the jet becomes divergent

• Support Inspection: Check the support bracket for cracks, deformation, or loose mounting bolts

• Lubrication: Apply anti-seize compound to threads during installation to prevent galling

• Torque Compliance: Tighten to the torque value specified in the equipment manual

• Full Depressurization: Always fully depressurize the waterjet system before servicing
