11-015415 – Valve Seat (Check Valve / Discharge Seat)

Short Description:

Direct waterjet supplier and factory, help maintain and solve waterjet technical problems, customize water jet solutions, provide robotic waterjet, 3D abrasive waterjet, as well as waterjet cutter heads parts and waterjet parts for KMT/FLOW/BHDT/TECHNI/RESATO/OMAX waterjet

INQUIRY

Details

Product ID: 11-015415 – Valve Seat (Check Valve / Discharge Seat)

Description:
This component is a high-pressure (HP) valve seat, specifically designed as a flat outlet or discharge seat for the check valve assembly in waterjet intensifier pumps. It is a precision-machined, disc-shaped consumable sealing component that serves as the stationary sealing surface. The seat works in conjunction with the corresponding inlet or outlet poppet to create a leak-tight, one-way seal, controlling the flow of pressurized water from the intensifier cylinder to the outlet manifold.

Applications:

Used as the stationary sealing surface in high-pressure check valve assemblies of waterjet intensifier pumps.
Suitable for ultra-high pressure waterjet systems typically operating at 60,000 PSI (approximately 4,137 bar).
Compatible with sealing head repair kits and check valve assemblies.

Features:

Consumable Component: The valve seat is a high-wear consumable part designed to protect the more expensive check valve body from damage.
Precision-Ground Sealing Surface: Machined to exact specifications for leak-tight shut-off when mated with the corresponding poppet.
High-Strength Material: Manufactured from wear-resistant, hardened stainless steel or specialized alloy to withstand repeated impact and high-velocity water flow.
Design Variant: This part uses a flat mating surface design, as opposed to a cone or ball type.

Maintenance:

Replacement Criteria: Replace the valve seat immediately if the sealing surface shows pitting, erosion, cracking, or indentation. A worn or damaged seat will cause pressure drop and prevent the check valve from sealing properly.
Simultaneous Replacement: Always replace the corresponding inlet or outlet poppet simultaneously with the valve seat. Reusing a worn poppet with a new seat (or vice versa) will compromise sealing.
Inspection: During pump overhaul, inspect the seat for wear. Even minor surface damage can cause pressure loss.
Full Depressurization: Always fully depressurize the waterjet system and follow lockout/tagout procedures before replacing the valve seat.
