Product Name: Adapter, JIC/Pipe, .50 x .50 – Part No. 05107875

Description:
This component is a hydraulic adapter designed to connect a JIC (Joint Industry Council) 37° flare fitting to a standard male pipe thread (NPT). The .50 x .50 designation indicates a 1/2 inch nominal size on both ends .

Its primary function is to serve as a transition fitting, allowing a hydraulic hose or component with a 1/2" JIC female swivel to be connected directly to a manifold, valve, or fitting that has a 1/2" female NPT port. According to the official parts diagram for the Bulkhead Pipe Assembly (P/N 72152927), this adapter is listed as Item 3 with a quantity of 2 required per assembly, confirming its role in the hydraulic system of waterjet cutting equipment .

The JIC end utilizes a 37° flare cone to create a reliable, vibration-resistant metal-to-metal seal. The male pipe end uses standard NPT (National Pipe Thread) tapered threads, which require a thread sealant (such as PTFE tape) to create a leak-proof seal.

Applications:

• Converts between 1/2" JIC female swivel connections and 1/2" NPT female ports.

• Used as a transition fitting in the Bulkhead Pipe Assembly (72152927) of waterjet hydraulic systems .

• Connects hydraulic hoses to components with different thread standards (JIC vs. NPT).

Features:

• JIC 37° Flare End: Provides a metal-to-metal seal, highly resistant to vibration and suitable for high-cycle applications.

• NPT Male Pipe End: Standard tapered pipe thread; requires PTFE tape or pipe sealant for sealing .

• Corrosion-Resistant Construction: Typically manufactured from steel with a protective plating or stainless steel to withstand harsh environments.

• Direct OEM Replacement: Interchangeable with manufacturer specifications as listed in the official parts diagram (Item 3 in Assembly 72152927) .

Maintenance:

Failure Diagnosis (When to Replace):

• External Fluid Leakage: Visible oil weeping at either connection. A leak at the JIC end indicates a damaged flare surface or loose nut; a leak at the NPT end indicates insufficient thread sealant or damaged threads.

• Thread Damage: Stripped, galled, or corroded threads on either end prevent proper tightening and sealing.

• JIC Flare Damage: Inspect the 37° flare surface for nicks, scratches, or deformation — any damage will cause high-pressure leaks.

• Cracked or Deformed Body: Any visible cracking or distortion of the adapter body requires immediate replacement.

Inspection and Replacement Guidelines:

• Full Depressurization (Critical): Before any maintenance, fully depressurize the hydraulic system, shut down the waterjet system, and follow lockout/tagout procedures.

• Thread Preparation (NPT End): Clean all threads thoroughly. Apply PTFE tape or a high-quality pipe thread sealant to the male NPT threads. Wrap tape in the direction of the threads (clockwise when looking at the end) to prevent unraveling.

• JIC Flare Inspection (JIC End): Carefully inspect the 37° male flare surface for damage; the JIC connection seals on the flare cone — do not use thread sealant on JIC threads.

• Torque Compliance: Tighten both connections to the specific torque values listed in the equipment service manual using a calibrated torque wrench.

• Two-Wrench Method: Use two wrenches — one to counter-hold the adapter and one to tighten the nut — to prevent twisting stress on the assembly.

• Replacement Criteria: Replace the adapter immediately if threads are damaged, the JIC flare surface is compromised, the body shows cracks, or persistent leakage occurs despite proper installation with new sealant.

Cross-Reference Information:

• OEM Part Number: 05107875

• Used in: Bulkhead Pipe Assembly 72152927 (Item 3, Qty 2)

• Connection Type: Male JIC 37° Flare x Male NPT Pipe

• Size: 1/2 inch (Nominal)
