English Translation of Title:
High-Pressure Tube for Water Jet Cutting Machine Parts – 38 mm x 450 mm, Model No. 10122315-HP-Tube-38-x-450.1262.3-1

Introduction, Application, Features, and Maintenance:

This component is a high-pressure straight tube designed for water jet cutting systems. It features a 38 mm nominal outer diameter and a length of 450 mm, and is used to convey high-pressure water or abrasive slurry between components in the machine’s hydraulic circuit.

Application:
Used as a rigid, straight conduit to connect high-pressure components in water jet cutting machines, such as between the pump and attenuator, attenuator and valve, or valve and cutting head. It is suitable for straight-line routing where flexible hoses or bent tubes are not required or practical.

Features:

• Rated for extreme pressures common in water jet cutting, up to 6,000 bar (87,000 psi).

• Straight design with 38 mm outer diameter and 450 mm length.

• Manufactured from high-strength, corrosion-resistant material suitable for high-velocity water and abrasive slurry.

• Smooth internal bore minimizes pressure loss and reduces erosion.

• Precision-machined ends ensure leak-proof connections with compatible fittings.

• Resistant to fatigue and vibration when properly supported.

Maintenance:

• Regularly inspect the entire tube length for signs of erosion, pitting, cracking, or external damage.

• Check both connection ends for high-pressure leakage during machine operation.

• Pay attention to areas near fittings or clamps where stress or abrasion may occur.

• Replace the tube immediately if any wall thinning, cracking, or leakage is detected.

• Ensure proper clamping and support to prevent excessive vibration.

• Clean the internal bore before installation to avoid contaminating downstream components.

• Follow specified torque values for all end connections.
