HT016011220-Quadring-Waterjet-Parts.1995.3-1

Short Description:

Used for BFT/BHDT pump.
We enable precise cutting and protect your efficient production.
With genuine BFT parts, your waterjet system always runs like new.
1. Performance revitalized, costs halved.
2. Choose BFT, choose reliability.

INQUIRY

Details

Product Name: Quad-Ring / X-Ring Seal (Part No. HT016011220)

Description:
This component is a Quad-Ring, also known as an X-ring or four-lobed seal, specifically designed for BHDT waterjet intensifier pumps . It is a precision elastomeric sealing component manufactured from high-grade, wear-resistant rubber or polyurethane material. Unlike a standard O-ring which has a circular cross-section, the Quad-Ring features a unique four-lobed (X-shaped) profile.

The Quad-Ring is a dynamic seal used within the high-pressure cylinder assembly of the intensifier pump . Its primary function is to seal the reciprocating plunger or piston rod, preventing ultra-high-pressure water from leaking past the moving component . The X-shaped cross-section provides four sealing surfaces, which significantly reduces friction and heat generation while enhancing sealing efficiency under high-pressure reciprocating motion. The Quad-Ring also holds a film of lubricant between the lobes, which further reduces friction and extends seal life.

Applications:

Provides the primary dynamic seal for the reciprocating plunger or piston rod in BHDT waterjet intensifier pumps
Installed within the high-pressure cylinder packing or seal stack assembly
Used during scheduled preventive maintenance, major pump overhauls, or when external water leakage is detected from the cylinder area
Suitable for ultra-high pressure waterjet systems operating at 60,000-94,000 PSI (approximately 4,137-6,480 bar)

Features:

Four-Lobed Profile: The X-shaped cross-section provides four sealing surfaces, offering more effective sealing than standard O-rings
Reduced Friction & Heat Generation: The lobes hold a lubricant film, minimizing friction and extending seal life under high-cycle operation
Pressure-Energized Design: The unique geometry causes the seal to expand against the sealing surfaces as system pressure increases
High Wear Resistance: Manufactured from premium elastomer materials to withstand millions of high-cycle strokes
Critical Consumable Component: As a dynamic elastomeric seal, it is classified as a high-wear consumable part requiring periodic replacement
OEM Compatibility: Direct replacement for BHDT part number HT016011220

Maintenance:

Failure Diagnosis (When to Replace) :

External Water Leakage: Visible water weeping from the high-pressure cylinder weep hole or end cover inspection hole is the primary indicator of Quad-Ring failure .
Pressure Drop: Inability to maintain rated cutting pressure suggests the Quad-Ring has worn or extruded, allowing internal water bypass .
Hydraulic Oil Contamination (Water Intrusion): Milky or discolored hydraulic oil may indicate high-pressure water has breached the dynamic seal .
Increased Pump Cycling Frequency: If the intensifier cycles more rapidly or frequently than normal, internal seal bypass is likely .
Visible Damage During Disassembly: When the pump is opened, inspect the Quad-Ring for nicks, cuts, flattening (compression set), cracking, or wear. Any visible damage warrants immediate replacement .
Scheduled Preventive Maintenance: It is standard industry practice to replace the Quad-Ring during scheduled major pump overhauls (typically based on operating hours) or whenever the high-pressure seal stack is serviced .

Inspection and Replacement Guidelines:

Full Depressurization (Critical): Before any maintenance, place the main electrical disconnect in the OFF position, bleed down all high-pressure lines, and follow lockout/tagout procedures .
Replace as Part of Complete Seal Set: When servicing the high-pressure sealing stack, it is recommended to replace all components (Quad-Ring, backup rings, support rings) simultaneously using a complete seal kit to ensure all components fit together correctly .
Clean Installation: Perform the rebuild in a designated clean area . Thoroughly clean the seal groove and all mating surfaces with a soft, lint-free cloth. Remove all debris, old seal residue, and mineral deposits .
Lubrication: Apply a thin, uniform layer of manufacturer-recommended high-pressure grease to the Quad-Ring during installation to prevent dry start-up, reduce friction, and ensure proper seating .
Orientation (Critical): Unlike a standard O-ring, the Quad-Ring has a specific cross-sectional profile. Ensure it is not twisted and is correctly seated in the groove .
Groove Inspection: Inspect the seal groove for nicks, burrs, sharp edges, or damage that could compromise the new seal .
Rod/Cylinder Bore Inspection: Before installing a new Quad-Ring, thoroughly inspect the reciprocating rod and cylinder bore surfaces for scoring, pitting, or damage. A damaged metal component will rapidly destroy a new seal .
Use Proper Tools: Use manufacturer-specified seal installation tools or sleeves to guide the Quad-Ring over threads and into the bore without rolling or pinching the sealing lobes .
