Short Description:

Used for BFT/BHDT pump.
We enable precise cutting and protect your efficient production.
With genuine BFT parts, your waterjet system always runs like new.
1. Performance revitalized, costs halved.
2. Choose BFT, choose reliability.

INQUIRY

Details

Product Name: Quad-Ring / Quadruple Sealing Ring (Part No. 9704521-220)

Description:
This component is a high-performance Quad-Ring, also known as a quadruple seal or X-ring, specifically designed for the HP (High-Pressure) sealing assembly in waterjet cutting systems . It is manufactured from premium elastomeric material (rubber) and is rated for extreme operating pressures up to 4,137 bar (approximately 60,000 PSI) .

Unlike a standard O-ring which has a circular cross-section, the Quad-Ring features a four-lobed (X-shaped) profile. This unique geometry provides four sealing surfaces, significantly reducing friction and wear while enhancing sealing efficiency under high-pressure reciprocating motion. The X-shaped cross-section also allows the seal to hold a film of lubricant between the lobes, which reduces friction and heat generation.

This Quad-Ring is a critical component within the pump's seal stack, used in conjunction with other supporting rings to create a leak-tight barrier . It is a standard consumable part for high-pressure waterjet intensifier pumps and is compatible with leading systems including BFT, BHDT, WJS, and Maximator Jet .

Applications:

Installed as a dynamic seal in the high-pressure cylinder packing assembly of waterjet intensifier pumps.
Serves as the primary sealing element in the CP022100/220 HP Seal Assembly and the CP-22-0684 Seal Kit .
Suitable for ultra-high pressure waterjet systems operating at 60,000+ PSI.
Compatible with BFT, BHDT, WJS, and Maximator Jet intensifier systems .

Features:

Four-Lobed Profile: Provides four sealing surfaces for more effective sealing than standard O-rings, while reducing friction.
Reduced Friction & Wear: The X-shape allows lubrication between the lobes, minimizing heat generation and extending seal life.
High-Pressure Rating: Engineered for continuous operation at pressures up to 4,137 bar (60,000+ PSI) .
Critical Wear Component: As a dynamic elastomeric seal, it is classified as a high-wear consumable part and must be replaced periodically .
OEM Compatibility: Direct replacement for BFT #9704521/220 and cross-referenced with OEM numbers 105335, 5300005, 10064, and 1-18269 .

Maintenance:

Failure Diagnosis (When to Replace) :

External Water Leakage: The most common indicator of Quad-Ring failure is water leaking from the cylinder end cover inspection hole or weep holes . According to OEM notes, if the inspection hole on the cylinder end cover leaks, the high-pressure water seal must be replaced immediately .
Pressure Drop: Inability to maintain rated cutting pressure suggests the Quad-Ring has worn or extruded, allowing internal water bypass.
Frequent System Cycling: If the intensifier pump cycles more rapidly or frequently than normal, internal seal failure is likely.
Scheduled Preventive Maintenance: It is standard industry practice to replace the Quad-Ring during scheduled major pump overhauls (typically every 1,000-2,000 operating hours) or whenever the HP seal assembly is serviced.
Visible Damage: If the pump is disassembled, inspect the Quad-Ring for nicks, cuts, flattening (compression set), or cracking. Any visible damage warrants immediate replacement.

Replacement and Inspection Guidelines :

Replace as Part of a Kit: This Quad-Ring is typically replaced as part of a complete seal assembly or repair kit (e.g., CP022100/220 or CP-22-0684), which includes the Quad-Ring, support ring, and backup ring together . Using a complete kit ensures all components fit together correctly.
Full Depressurization (Critical): Before any maintenance, place the main electrical disconnect in the OFF position, bleed down all high-pressure lines, and follow lockout/tagout procedures.
Clean Installation: Perform the rebuild in a clean area. Thoroughly clean the seal groove and all mating surfaces with a soft cloth. Remove all debris, old seal residue, and mineral deposits.
Lubrication: Apply a thin, uniform layer of high-pressure grease to the Quad-Ring during installation to prevent dry start-up, reduce friction, and ensure proper seating.
Groove Inspection: Inspect the seal groove for nicks, burrs, or sharp edges that could damage the new seal.
OEM Note: Because BHDT equipment uses a combination of hard and soft seals in the high-pressure cylinder, it is recommended to purchase all components of the high-pressure water seal together to facilitate proper installation .
