Short Description:

Used for BFT/BHDT pump.
We enable precise cutting and protect your efficient production.
With genuine BFT parts, your waterjet system always runs like new.
1. Performance revitalized, costs halved.
2. Choose BFT, choose reliability.

INQUIRY

Details

Product Name: Distance Bushing / Spacer Bushing (Part No. CP022013/014)

Description:
This component is a distance bushing, also referred to as a spacer bushing or compensating sleeve, specifically designed for BFT waterjet intensifier pumps . It is a precision-machined cylindrical component typically manufactured from high-strength steel or brass .

The primary function of the distance bushing is to act as a spacer for the high-pressure dynamic seals within the high-pressure cylinder assembly . It is installed inside the stainless steel high-pressure cylinder, positioned between dynamic seal components to maintain proper axial spacing and alignment within the seal stack . This component ensures that the high-pressure seals remain correctly positioned, preventing seal movement or extrusion under extreme pressure cycling.

The bushing is also described as a cylinder insert that protects the high-pressure cylinder bore. By serving as a sacrificial wear surface, it prevents direct contact between the dynamic seal stack and the inner wall of the expensive high-pressure cylinder, thereby extending the life of the cylinder itself . It is rated for continuous operation at 4,137 bar (approximately 60,000 PSI) .

This component is a standard part in BFT intensifier assemblies, including CP022001/2 and HT022012/172 . It is fully compatible with other major waterjet intensifier systems including WJS, Maximator Jet, STM, and Intermac Primus . Cross-reference part numbers include 1-16392, 5300006, 106566, 10044, and HD400075 .

Applications:

Provides proper spacing and positioning for high-pressure dynamic seals within the high-pressure cylinder assembly
Protects the high-pressure cylinder bore from wear by acting as a sacrificial surface
Maintains correct alignment of the seal stack under ultra-high pressure operation
Used during scheduled preventive maintenance, major pump overhauls, or when seal stack integrity is compromised
Suitable for ultra-high pressure waterjet systems operating at 60,000 PSI (4,137 bar) and above
Compatible with BFT, WJS, Maximator Jet, STM, and Intermac Primus waterjet intensifier systems

Features:

High-Strength Steel or Brass Construction: Precision-machined from durable, corrosion-resistant material to withstand extreme pressure cycling
Critical Spacing Function: Maintains precise axial spacing between dynamic seal components in the high-pressure seal stack
Cylinder Protection: Serves as an insert that prevents direct friction between seal components and the high-pressure cylinder bore, protecting the expensive cylinder from wear
High-Pressure Rating: Engineered for continuous operation at 4,137 bar (60,000+ PSI)
Lightweight: Approximately 0.1 kg for easy handling during maintenance
OEM Compatibility: Direct replacement for BFT part number CP022013/014; cross-referenced with 1-16392, 5300006, 106566, 10044, and HD400075

Maintenance:

Failure Diagnosis (When to Inspect/Replace):

Seal Stack Issues: If the high-pressure seals fail prematurely or external water leakage occurs, the distance bushing may be worn or damaged
Cylinder Bore Damage: Scoring or wear on the high-pressure cylinder bore may indicate the bushing has failed to protect the cylinder surface
Visible Wear During Overhaul: During pump disassembly, inspect the bushing for signs of scoring, galling, deformation, or wear
Dimensional Integrity: Measure the bushing length and diameter to detect any dimensional change that could affect seal stack spacing
Scheduled Preventive Maintenance: It is standard practice to inspect the distance bushing during major pump overhauls and replace it if any wear or damage is detected

Inspection and Replacement Guidelines:

Full Depressurization (Critical): Before any maintenance, fully depressurize the waterjet system (high-pressure water, hydraulic system, and air supply) and follow lockout/tagout procedures
Clean Area Maintenance: Perform the rebuild in a designated clean area to prevent contamination of components with abrasive particles
Disassembly: Remove the high-pressure cylinder end cap and extract the seal stack to access the distance bushing
Thorough Cleaning: Clean the bushing and its mounting cavity with a soft cloth and low-pressure water. Remove all debris, old seal residue, and mineral deposits. Do not use abrasive tools
Surface Inspection: Inspect the bushing outer and inner surfaces for scoring, pitting, galling, or uneven wear patterns
Dimensional Measurement: Measure the bushing length and diameter at multiple points using precision measuring tools to detect out-of-tolerance conditions
Replace as a Set: When servicing the high-pressure seal stack, it is recommended to replace the distance bushing simultaneously with the dynamic seals, O-rings, and backup rings to ensure optimal seal stack performance
Cylinder Bore Inspection: When replacing the distance bushing, inspect the high-pressure cylinder bore for scoring, pitting, or wear. Replace the cylinder if damage is found, as a damaged cylinder will compromise seal performance
Lubrication: Apply a thin, uniform layer of manufacturer-recommended high-pressure grease to the bushing during installation
Torque Compliance: When reassembling the cylinder end cap, tighten all retaining hardware to the specific torque values listed in the equipment service manual
Recommended Purchase: To ensure proper fit and reduce machine downtime, it is advisable to purchase the high-pressure cylinder and distance bushing together as a matched set
Storage: Store spare bushings in a clean, dry environment to prevent surface damage before use
