English Translation of Title:
Adapter for Water Jet Cutting Machine Parts – Pipe to Solenoid Valve, Model No. 72150853-Adapter-PipeSolenoid-Valve.1342.3-1

Introduction, Application, Features, and Maintenance:

This component is an adapter designed for water jet cutting systems. It converts between a standard pipe (NPT or BSP) connection and a solenoid valve port, allowing a pipe system to be connected directly to a solenoid valve.

Application:
Used to connect standard piping to solenoid valves in water jet cutting machines. Typical installations include connecting water, abrasive slurry, or hydraulic fluid supply lines to solenoid valves for automated on/off or directional control.

Features:

• Rated for pressures appropriate to the system design (may vary from low‑pressure to high‑pressure applications).

• Converts between standard pipe thread (NPT or BSP) and solenoid valve connection standards.

• Manufactured from high‑strength, corrosion‑resistant material suitable for water and abrasive slurry exposure.

• Precision‑machined threads and sealing surfaces ensure leak‑free operation.

• Compact design minimizes space requirements and reduces potential leak points.

• Facilitates easy installation and replacement of solenoid valves.

Maintenance:

• Regularly inspect the adapter body, pipe threads, and sealing surfaces for signs of erosion, cracking, or corrosion.

• Check for leakage at both connection ends during machine operation.

• Replace immediately if any leakage, surface pitting, or thread damage is detected.

• Use compatible thread sealant or tape on the pipe thread side as required.

• Inspect the solenoid valve connection area for damage that could compromise sealing.

• Follow specified torque values when tightening both connection ends.
