English Translation of Title:
Water Jet Pump Tube Vise – 75 mm, Model No. 20437825-Water-Jet-Pump-Tube-Vise-75.1021.3-1

Introduction, Application, Features, and Maintenance:

This component is a tube vise designed for water jet pump systems. It is a clamping device used to securely hold, support, or position high-pressure tubes or pipes within the machine, featuring a 75 mm capacity.

Application:
Used to secure and stabilize high-pressure tubing in water jet cutting machines. Typical installations include mounting tube bundles, supporting rigid lines near the pump or cutting head, and preventing vibration-induced movement or fatigue in critical piping sections.

Features:

• Designed for 75 mm outer diameter tubes or pipes.

• Provides secure clamping to prevent tube movement and reduce vibration.

• Manufactured from high-strength, corrosion-resistant material suitable for harsh water jet environments.

• May include protective liners (e.g., rubber or plastic) to prevent tube damage.

• Adjustable or fixed design for easy installation and alignment.

• Helps extend tube service life by minimizing stress and fatigue.

Maintenance:

• Regularly inspect the vise body, clamping surfaces, and fasteners for signs of corrosion, wear, or loosening.

• Check that the clamped tube remains secure and properly aligned.

• Inspect protective liners for wear or damage that could expose the tube to metal contact.

• Replace the vise immediately if any cracks, deformation, or loss of clamping force is observed.

• Follow specified torque values for mounting fasteners.

• Clean the clamping area periodically to prevent abrasive particle buildup.
