Short Description:

Used for BFT/BHDT pump.
We enable precise cutting and protect your efficient production.
With genuine BFT parts, your waterjet system always runs like new.
1. Performance revitalized, costs halved.
2. Choose BFT, choose reliability.

INQUIRY

Details

Product Name: Sealing Ring / Backup Ring (Part No. DR006001220)

Description:
This component is a Sealing Ring, often used as a Backup Ring (Back-up Ring) or support ring in high-pressure hydraulic or waterjet systems [citation:1]. The designation "NS6" typically refers to a standardized dimension or profile class [citation:4].

Manufactured from a rigid, wear-resistant material (such as PTFE, PEEK, or specialized polymer), it is designed to be installed adjacent to an O-ring or elastomeric seal. Its primary function is to provide anti-extrusion support, preventing the softer seal material from being forced into the clearance gap under extreme pressure [citation:1]. This component is specifically engineered for static sealing applications in BHDT high-pressure intensifier pumps.

Applications:

Provides anti-extrusion support for O-rings in high-pressure static sealing applications.
Installed in the sealing head, check valve assemblies, or cylinder interfaces of BHDT waterjet intensifier pumps.
Suitable for ultra-high pressure systems operating at 60,000-94,000 PSI (approximately 4,137-6,480 bar) [citation:4].

Features:

Rigid Material: Made from high-strength polymer or metal to withstand extrusion forces.
Anti-Extrusion Function: Fills the radial gap to protect the primary O-ring from pressure damage [citation:1].
Precision Dimensions: Machined to exact tolerances for a secure fit in the designated groove.
BHDT OEM Specification: Directly compatible with BHDT high-pressure components.

Maintenance:

Failure Diagnosis (When to Replace):

External Water Leakage: Visible leakage from the sealed interface often indicates primary O-ring failure, requiring replacement of both the O-ring and this backup ring.
Pressure Drop: Inability to maintain system pressure may be caused by extrusion damage to the O-ring due to a worn or missing backup ring.
Visible Damage: During disassembly, inspect the ring for cracking, flattening, deformation, or splitting. Any damage warrants immediate replacement [citation:1].

Inspection and Replacement Guidelines:

Full Depressurization (Critical): Before any maintenance, fully depressurize the waterjet system and follow lockout/tagout procedures.
Single-Use Component: This is a consumable part. Always replace it together with the adjacent O-ring [citation:1]. Do not reuse old rings.
Clean Installation: Clean the seal groove thoroughly before installing the new ring.
Lubrication: Apply a thin layer of high-pressure grease to the backup ring and O-ring during assembly to prevent pinching [citation:1].
