Product Name: JE to IDE III Adapter (Part No. 100205-1)

Description:
The JE to IDE III Adapter (Part No. 100205-1) is a precision-machined stainless steel component designed to mount a Jet Edge (JE) style cutting head to the newer Integral Diamond Eductor (IDE) III cutting head assembly on a waterjet system . It facilitates the transition from an older Jet Edge interface to the advanced IDE III platform, eliminating the need to replace the entire Z-axis motion system.

Applications:

• Mounting an IDE III cutting head onto a machine originally equipped with a Jet Edge (JE) style cutting head .

• Retrofitting older Jet Edge waterjet systems to accept H2O Jet IDE components.

• Allowing the use of longer-life IDE III consumables (diamond orifice, mixing tube) on legacy Jet Edge equipment.

Features:

• Precision Machined: Manufactured from high-strength, corrosion-resistant stainless steel to ensure perfect coaxial alignment between the retrofitted components.

• Direct Fit: Engineered specifically to bridge the dimensional differences between the Jet Edge mounting interface and the IDE III body .

• Retrofit Enabler: Provides a cost-effective upgrade path to the IDE III platform without replacing the entire cutting head motion system .

Maintenance:

• Inspect Sealing Surfaces: Regularly check the mating faces and cone seats for nicks, scratches, or erosion.

• Full Depressurization: Always fully depressurize the waterjet system before installing or removing the adapter.

• Torque Compliance: Tighten the adapter and gland nuts to the specific torque values listed in the equipment service manual to prevent high-pressure leaks.

• Lubrication: Apply high-pressure anti-seize lubricant to the threads during reassembly to prevent galling.

•
