English Translation of Title:
High-Pressure Cross Fitting for Water Jet Cutter Parts – 25 mm, Model No. 10097228-HP-Water-Jet-Cutter-Parts-Cross-25.935.3-1

Introduction, Application, Features, and Maintenance:

This component is a high-pressure cross fitting designed for water jet cutting systems. It features four connection ports arranged in a cross configuration, all with a 25 mm interface, allowing multiple directional flow paths within the high-pressure plumbing network.

Application:
Used to distribute, collect, or redirect high-pressure water or abrasive slurry flow in water jet cutting machines. Typical installations include manifold systems, supplying multiple cutting heads from a single pump, combining return lines, or integrating pressure sensors and bypass circuits.

Features:

• Rated for extreme pressures common in water jet cutting, up to 6,000 bar (87,000 psi).

• Four equal ports at 25 mm interface size, arranged in a cross pattern.

• Allows simultaneous flow in multiple directions with minimal pressure loss.

• Manufactured from high-strength, corrosion-resistant material suitable for abrasive water jet media.

• Precision-machined sealing surfaces ensure leak-free connections.

• Compact design facilitates integration into dense hydraulic layouts.

Maintenance:

• Regularly inspect all four ports and the cross body for signs of erosion, cracking, or leakage.

• Check for uneven flow or pressure drops at branch ports, which may indicate internal wear or blockage.

• Replace immediately if any surface pitting, thread damage, or visible wear is detected.

• Follow specified torque values when tightening all four connections.

• Use only compatible seals and washers during reassembly.
