05121512-Autoline-TM-Diamond-Orifice-0016-0406-mm.973.3-1
Title Translation:
Blade Cutting Equipment Accessory, Name/Code: 05121512-Autoline-TM-Diamond-Orifice-0016-0406-mm.973.3-1
Introduction:
This component is a diamond orifice designed for automated blade cutting lines. It functions as a high-precision flow control element, directing cutting fluid such as coolant, lubricant, or abrasive slurry to the blade cutting zone with superior wear resistance.
Applications:
Used in precision automated cutting systems for dicing, slicing, or grooving hard and brittle materials including ceramics, glass, semiconductors, and composite substrates.
Features:
Diamond construction offers extreme hardness and extended operational life.
Excellent thermal conductivity and chemical resistance.
Precisely calibrated orifice diameter (0016-0406 mm) ensures uniform fluid delivery.
Withstands high-frequency vibration and abrasive flow environments.
Maintenance:
Inspect regularly under magnification for cracks, wear, or blockage.
Clean using ultrasonic or non-abrasive methods with compatible solvents.
Do not use metal tools that may scratch or chip the diamond surface.
Replace immediately if flow pattern becomes irregular or damage is visible.
Not repairable; replacement only when worn or damaged.
