Autoline™ Diamond Orifice for Water Jet Cutting Machine Parts – 0.004 x 0.102 mm, Model No. 20448625-Autoline-TM-Diamond-Orifice-00040102-mm.963.3-1

(Note: The dimensions "0.004 x 0.102 mm" represent the orifice diameter and length, or are internal reference codes. Diamond orifices are precision components with extremely small bore sizes, typically measured in thousandths of an inch or hundredths of a millimeter.)

Introduction, Application, Features, and Maintenance:

This component is a diamond orifice designed for the Autoline™ series of abrasive water jet cutting systems. It is a precision‑machined jewel (synthetic diamond) with a very small, accurately sized hole that regulates the flow of high‑pressure water into the mixing chamber, where it combines with abrasive to form the cutting jet.

Application:
Used in the cutting head assembly of Autoline™ abrasive water jet cutting machines. The orifice is the first component that high‑pressure water passes through, creating a high‑velocity water jet that entrains abrasive particles in the mixing chamber. It is critical for achieving precise, consistent cutting performance.

Features:

• Precision‑machined synthetic diamond provides extreme wear and erosion resistance.

• Orifice size: 0.004 inch diameter with 0.102 mm length reference (or internal code).

• Creates a focused, high‑velocity water jet for optimal abrasive entrainment.

• Directly influences cutting speed, accuracy, kerf width, and nozzle life.

• Designed specifically for Autoline™ series cutting heads for proper fit and performance.

• Engineered as a consumable wear component for easy replacement.

Maintenance:

• Inspect the diamond orifice regularly for signs of wear, erosion, or clogging.

• Monitor cutting performance; slower cutting, wider kerf, or rough edges may indicate orifice wear.

• Replace the orifice immediately when the bore exceeds tolerance or when cut quality degrades.

• Handle with care to avoid damaging the delicate diamond material.

• Clean the orifice and surrounding components to prevent debris accumulation.

• Follow the manufacturer’s recommended replacement intervals based on operating hours.
