A2260003-Standard-Sapphire-Orifice-0003-0076-mm.1069.3-1

Short Description:

The company is a world-leading manufacturer of high-pressure water jet pumps.
The SL-VI 50HP pump is a highly classic and popular industrial high-pressure pump.
We offer original accessories and professional technical support.

INQUIRY

Details

English Translation of Title:
Standard Sapphire Orifice 0.003–0.076 mm – Waterjet Cutting Equipment Accessory (ID: A2260003)

Description, Purpose, Features, and Maintenance:

This component is a precision synthetic sapphire orifice with a flow diameter ranging from 0.003 mm to 0.076 mm. It is installed at the waterjet cutting head, positioned before the abrasive mixing chamber, to convert ultra‑high‑pressure water into a coherent, high‑velocity jet that entrains abrasive particles for efficient material cutting.

Purpose:

Restricts and accelerates water flow at pressures up to 6,000 bar to produce a stable, focused cutting stream.
Regulates water volume and jet diameter to optimise abrasive mixing and cutting performance for various material thicknesses.
Acts as the critical flow‑control element that determines jet coherence, cutting speed, and edge quality.

Features:

Made from synthetic sapphire (single‑crystal aluminium oxide) for exceptional hardness and wear resistance.
Precision‑machined bore ensures consistent flow characteristics and minimal jet divergence.
Chemically inert and fully corrosion‑resistant in high‑pressure water and abrasive slurry environments.
Maintains dimensional stability under extreme pressure and temperature variations.
Compact design enables rapid, tool‑free replacement in most cutting head assemblies.

Maintenance:

Replace when cutting performance degrades, indicated by slower feed rates, wider kerf, or rougher cut surfaces.
Inspect under magnification for erosion, cracking, or bore enlargement after every 80–120 operating hours.
Handle exclusively with non‑metallic tweezers; avoid touching the orifice surface to prevent contamination.
Clean using an ultrasonic bath with deionised water only; do not use abrasive cleaners or harsh solvents.
Install with the correct flow direction (marked on the component) to ensure proper jet formation.
Store spare units in a cushioned, dust‑tight container to protect against impact damage and particulate contamination.
