95383790-Socket-Head-Screw-12-13-x-1-Waterjet-Pump.838.3-1

Short Description:

The company is a world-leading manufacturer of high-pressure water jet pumps.
The SL-VI 50HP pump is a highly classic and popular industrial high-pressure pump.
We offer original accessories and professional technical support.

INQUIRY

Details

English Translation of Title:
Socket Head Screw for waterjet pump – 1/2-13 x 1 inch, Model No. 95383790-Socket-Head-Screw-12-13-x-1-Waterjet-Pump.838.3-1

Introduction, Application, Features, and Maintenance:

This component is a socket head cap screw, a high-strength threaded fastener, designed for use in waterjet cutting systems. It is a 1/2 inch nominal diameter fastener with 13 threads per inch (coarse thread series), with a 1-inch length. The screw features a cylindrical head with a hexagonal socket drive.

Application:
Used to secure critical components in waterjet pump systems. Based on standard parts lists, it is commonly used as one of four screws in an intensifier support assembly and is also part of a Redundant Kit, indicating its role in securing components to ensure continuous operation. Typical applications include mounting hydraulic components, securing covers, and fastening structural frame connections.

Features:

Thread Size: 1/2-13 (coarse thread, Unified Inch Standard).
Length: 1 inch.
High-Strength Design: Manufactured from high-strength, corrosion-resistant material to withstand harsh waterjet environments.
Socket Drive: The hexagonal socket (Allen) drive allows for easy installation and removal with standard hex keys.
Precision Fit: Designed to meet exact specifications for waterjet pump assemblies, ensuring correct clamping force and alignment.

Maintenance:

Inspection: Regularly inspect the screw for signs of corrosion, thread damage, or stripping. Check for loosening of fastened components during routine machine inspection.
Torque: It is critical to tighten the screw to the specified torque to ensure proper clamping force and prevent over-stressing. Note: Specific torque values may vary by application; refer to the manufacturer's pump manual for the correct specification.
Replacement: Replace immediately if threads are damaged, stripped, or if the head shows signs of deformation or wear.
Thread Compound: Consider using a thread-locking compound if the screw is subject to vibration.
