English Translation of Title:
2-Way Straight Fitting for waterjet pump Parts – 75 mm, Model No. 20432554-2-Way-Straight-75-Waterjet-Pump-Parts.913.3-1

Introduction, Application, Features, and Maintenance:

This component is a 2‑way straight fitting designed for water jet cutting pump systems. It provides a straight‑through connection between two high‑pressure lines or components, both with a 75 mm nominal size, ensuring uninterrupted flow with minimal pressure drop.

Application:
Used to connect, extend, or align high‑pressure lines in water jet cutting machines. Typical installations include connections between pump outlets, attenuators, valves, and cutting head supply lines where a straight, in‑line connection is required.

Features:

• Rated for extreme pressures common in water jet cutting, up to 6,000 bar (87,000 psi).

• Straight‑through 2‑way design maintains linear flow with minimal pressure loss.

• Both ends feature 75 mm nominal size for direct compatibility.

• Manufactured from high‑strength, corrosion‑resistant material suitable for abrasive water jet media.

• Precision‑machined sealing surfaces ensure leak‑free operation.

• Compact design minimizes space requirements and reduces potential leak points.

Maintenance:

• Regularly inspect the fitting body and threads for signs of erosion, cracking, or thread damage.

• Check both connection ends for high‑pressure leakage during machine operation.

• Replace immediately if any surface pitting, thread damage, or leakage is detected.

• Use compatible seals, washers, or thread sealants as required.

• Follow specified torque values when tightening both connection ends.
