Short Description:

The company is a world-leading manufacturer of high-pressure water jet pumps.
The SL-VI 50HP pump is a highly classic and popular industrial high-pressure pump.
We offer original accessories and professional technical support.

INQUIRY

Details

English Translation of Title:
Standard Sapphire Orifice 0.009–0.229 mm – Waterjet Cutting Equipment Accessory (ID: A2260009)

Description, Purpose, Features, and Maintenance:

This component is a precision synthetic sapphire orifice with a flow diameter ranging from 0.009 mm to 0.229 mm. It is installed at the waterjet cutting head, positioned before the abrasive mixing chamber, where it converts ultra‑high‑pressure water into a coherent, high‑velocity jet that entrains abrasive particles for cutting thick or difficult‑to‑cut materials.

Purpose:

Restricts and accelerates water flow at pressures up to 6,000 bar to generate a stable, focused cutting stream.
Regulates water volume and jet diameter to accommodate heavy‑section materials and high‑speed cutting requirements.
Acts as the critical flow‑control element that determines jet coherence, abrasive mixing efficiency, and edge quality.

Features:

Fabricated from synthetic sapphire (single‑crystal aluminium oxide) for exceptional hardness and wear resistance.
Precision‑machined bore ensures consistent flow characteristics and minimal jet divergence.
Chemically inert and fully corrosion‑resistant in high‑pressure water and abrasive slurry environments.
Maintains dimensional stability under extreme pressure and temperature variations.
Compact design enables rapid, tool‑free replacement in most cutting head assemblies.

Maintenance:

Replace when cutting performance degrades, indicated by slower feed rates, wider kerf, rougher cut surfaces, or increased taper.
Inspect under magnification for erosion, cracking, or bore enlargement after every 80–120 operating hours.
Handle exclusively with non‑metallic tweezers; avoid touching the orifice surface to prevent contamination.
Clean using an ultrasonic bath with deionised water only; do not use abrasive cleaners or harsh solvents.
Install with the correct flow direction (marked on the component) to ensure proper jet formation.
Store spare units in a cushioned, dust‑tight container to protect against impact damage and particulate contamination.
